The Best Inline Water Filter

Pure and Simple

Filter Body Designs

The CL-Series

Our original CL-Series has been a mainstay of our line since 1970. This simple but effective design incorporates the features that have made our filters the best in the world.
The filters are produced in 6" and 10" lengths with a diameter of 2", available with 1/8", 1/4" and 3/8" female NPT, service life up to 1500 gallons and cubic inch volumes up to 16.6.
All standard media choices are available as well as custom fill options.
USES: Icemakers, under the counter, drinking fountains, beverage equipment, R.O. Systems, and in conjunction with commercial purification systems.

The K-Series

The fastest growing segment of our business, the K-Series, features the new Quick-Connect compression fittings that allow for installation and replacement in a matter of seconds without the use of tools. The K-Series also offers an expanded selection of body sizes including a corresponding housing for R.O. membranes. K-Series lengths are 6", 8", 10", and 12", available in 2"and 2-1/2" diameters. Volumes reach 35 cu.in. and service life maximums of 2500 gallons. Quick-Connect fittings are available in 1/4" or female NPTs are offered in 1/8", 1/4", 3/8". All standard media and custom fills are available.
USES: R.O. Systems, icemakers, under the counter, drinking fountains, beverage equipment, and in conjunction with purification systems.

The B-Series

Designed specifically for the commercial beverage industry, the B-Series features the unique "Twist-Tap" in-head valve system. The "Twist-Tap" system automatically turns the supply water off when the body is unscrewed.
Lengths are 6", 8", 10", and 12", available in 2-1/2" diameters. Volumes reach 35 cu.in. and service life maximums are 2500 gallons. Female threads are offered in 1/4"or 3/8" NPT. All standard media and custom fills are available.
USES: Commercial beverage equipment, espresso machines, R.O. Systems, icemakers, under the counter, drinking fountains, and in conjunction with purification systems.

The Q-Series

The Q-Series was introduced in response to customer requests for a cost-effective alternative to similar pro-
ducts on the market. The design features a permanent
head with a replaceable filter body. Replacement of spent media is completed with the twist of a wrist, in a matter of seconds, without the use of tools. Best of all, Omnipure has perfected a manufacturing technique that allows us to offer this unique filter at a lower cost than similar products on the market.
Lengths are 6", 8", 10", and 12", available in 2-1/2" diameters. Volumes reach 35 cu.in. and service life maximums are 2500 gallons. Female threads are offered in 1/4"or 3/8" NPT. All standard media and custom fills are available.
USES: Commercial beverage equipment, espresso machines, R.O. Systems, icemakers, under the counter, drinking fountains, and in conjunction with purification systems.

The OC-Series Filter Elements

With the highest volume in the industry, the OC-Series filter elements are designed to fit most standard 4-7/8", 9-3/4" and 20" cartridge housings. Omnipure utilizes a spring-loading device to compress the media into a tight block, reducing media migration and ensuring that the water passes properly through the media for optimum filtration. Polypropylene components are ultrasonically welded together, eliminating glues and binders that can cause contamination, while assuring a clean, uncontaminated filter element.
USES: R.O. Systems, icemakers, under the counter, drinking fountains, beverage equipment, and in conjunction with purification systems.
